Wylex DSF100M 100A DP Metal Enclosed Domestic Switch Fuse with 100A Fuse

*Free next day delivery for orders over £200*

(Orders must be placed before 2pm, excludes weekends & subject to stock availability)

Wylex DSF100M 100A DP Metal Enclosed Domestic Switch Fuse with 100A Fuse Features & Benefits:

• Domestic switch fuse (cw 100A fuse)
• Double pole lockable switch mechanism
• All metal enclosure
• For the connection of sub mains or system extensions

Wylex DSF100M 100A DP Metal Enclosed Domestic Switch Fuse with 100A Fuse Specifications:

Version as main switch No
Version as maintenance-/service switch Yes
Max. rated operation voltage Ue AC 400 V
Rated operating voltage 230-400 V
Rated permanent current Iu 100 A
Conditioned rated short-circuit current Iq 16 kA
Number of poles 2
Motor drive optional No
Voltage release optional No
Suitable for distribution board installation No
Type of control element Toggle
Interlockable No
Type of electrical connection of main circuit Screw connection
Degree of protection (IP), front side IP20
Product Standard/s     BS EN 60947-3
Terminal Capacity L&N 35 mm²
Terminal Capacity E 16 mm²
CE Conformity Yes
WEEE Symbol Yes
UKCA Conformity Yes
Height 302 mm
Width 178 mm
Depth 111 mm
