Wylex NMT2SPD3W/1 40kA 1 Module SP&N Type 2 Surge Protection Device

*Free next day delivery for orders over £200*

(Orders must be placed before 2pm, excludes weekends & subject to stock availability)

The Wylex NMT2SPD3W/1 is 40kA 1 Module SP&N Type 2 Surge Protection Device

Wylex NMT2SPD3W/1 40kA 1 Module SP&N Type 2 Surge Protection Device Features & Benefits:

• Type 2 SPD kit
• For Wylex consumer units
• DIN rail mounting, single module, including all connections
• Status indication and volt free contact for remote monitoring
• Replacement protective element (cartridge) is available, NMT2SPD/P

Wylex NMT2SPD3W/1 40kA 1 Module SP&N Type 2 Surge Protection Device Specification:

System configuration TN-C-S Yes
System configuration TN-S Yes
System configuration TT Yes
Nominal discharge surge current (8/20) 20 kA
Short-circuit breaking capacity (Isccr) 25 kA
Max. continuous voltage AC 275 V
Max. discharge surge current (8/20) 40 kA
Mounting method DIN rail (top hat rail) 35 mm
Construction size 1 modular spacing
Voltage protection level 1.3 kV
Max. conductor cross section solid (solid, stranded) 25 mm²
Voltage protection level L-N 1.3 kV
Voltage protection level N-PE 1.3 kV
With remote signalling contact Yes
Integrated backup fuse No
Category type 2 Yes
Degree of protection (IP) IP20
Product Standard/s IEC EN 61643-11
Frequency 50 Hz
CE Conformity Yes
WEEE Symbol Yes
UKCA Conformity Yes
Height 85 mm
Width 18 mm
Depth 70 mm
